Our company can supply many kinds of atomized alloy powders，including iron - based, nickel - based, cobalt - based and copper - based atomized alloy powders. We also can accept customized powders with different chemical composition and particle size distribution.
With many years of experience in atomizing powder production, we can provide a wide range of products with average particle size of 3 ~ 150um ，the powder’s shape can be spherical or irregular according to customers’ requirements. All kinds of products have the advantages of high purity, low oxygen content and less non-metallic inclusion.
Our products can be used in the following products：Diamond tools, Engine valve seat and guide, Porous filter pipe，etc.
| Products | Base Element | Sintering Temperature （℃） |
Hardness (HRB) |
Sintering Density （g/cm³ ） |
Oxygen Content （PPM） |
Mean Size D50(μm) |
Main Application |
| Follow100 | Fe-based | 750-810 | 101-102 | 8.01-8.15 | <3000 | 15-25 | Granite，Glass |
| Follow107 | Fe-based | 750-830 | 100-110 | 7.50-8.00 | <3000 | 20-30 | Granite，Ceramic |
| Follow200 | Cu-based | 680-730 | 97-98 | 8.55-8.72 | <2500 | 10-20 | Laser Weld |
| Follow400 | Fe-based | 700-750 | 106-108 | 7.93-8.03 | <3000 | 15-25 | Soft Stone，Ceramic |
| Follow500 | Ni-based | 750-800 | 40-45(HRC） | 7.15-7.20 | <2000 | 10-20 | Laser Weld，Concrete |
| FJ-01 | Fe-based | 800-850 | 60-65(HRC） | 7.69-7.85 | <2000 | <25 | Wear resistant |
| FQH10 | Ni-based | 760-800 | 40-45(HRC） | 7.15-7.25 | <3000 | <29 | brazing |
| CuNiMnSi | Cu-based | 700-750 | 150-200（HV0.20） | 8.33-8.5 | <500 | <35 | Diamond Drill |
| CuSn | We can provide CuSn alloy powders, include CuSn10, CuSn15, CuSn20 etc., which are producted by high press water atomization | ||||||
| Products | Chemical Composition | ||||||||
| Cr | Mo | Ni | Co | Si | V | W | C | Fe | |
| M7 | 25 | 25 | 10 | Bal. | 1 | – | – | – | – |
| M3-2 | 4 | 6 | – | 0.5 | 0.3 | 3 | 6 | 0.9 | Bal. |
| T400 | 8.5 | 28.5 | – | Bal. | 2.5 | – | – | – | – |
| Item | Particle Size Distribution (Mesh) | Oxygen content （PPM） |
Apparent density (g/cm³) | Hardness (HRB) | Crushing Strength (MPa) | ||||
| +150 | -150+250 | -250+325 | -325+400 | -400 | |||||
| Testing | <1 | <10 | <25 | <10 | >55 | <2500 | 2.0-3.0 | 85-102 | >500 |
| Products | Apparent Density (g/cm³) | Flowability (s/50g) |
Oxygen Content （PPM） |
Sieve Size (mesh) |
Green Density（g/cm³） |
| 316L | 2.7-2.9 | <40 | <2500 | -80, -100, -400 | >6.5 |
| Fe3Al | 1.4～2.1 | <60 | <4500 | -40，-500 | — |
| Products | Similar Steel Grades | Chemical Composition | ||||||||
| Bohler | Erasteel | Crucible | Hachi | C | W | Mo | Cr | V | Co | |
| AHP M3 | S790 | ASP2030 | REX M3-1 |
FAX31 | 1.3 | 6.2 | 5 | 4 | 3 | |
| AHP M4 | S690 | EM4 | CPM M4 | 1.35 | 5.5 | 4.7 | 4.2 | 4 | ||
| AHP T15 | ASP2015 | CPM T15 | FAX55 | 1.55 | 12 | – | 4 | 5 | 5 | |
| AHP T15M | S390 | ASP2052 | 1.6 | 10 | 2.2 | 4.7 | 4.8 | 8 | ||
| AHP 2030 | S590 | ASP2030 | CPM REX45 |
FAX38 | 1.3 | 6.5 | 4.9 | 4 | 2.9 | 8.3 |
| AHP 2060 | ASP2060 | 2.3 | 6.5 | 7.0 | 4.2 | 6.5 | 10.5 | |||
| AHP 10V | CPM 10V | 2.45 | 1.3 | 5.25 | 10 | |||||
